Stainless Steel 321 Washers Manufacturer and Supplier
ASTM A194 / A193 Stainless Steel 321 Washer, SS 321 Washer, Steel UNS S32100 Washer, Stainless Steel Werkstoff Nr. 1.4541 Washer Dealers & Exporters
Most Prominent Stainless Steel 321 Washer Stockist, SS 321 Washer Supplier, 321 Steel Washers Manufacture in India
Mahabali Steel Centre is a prominent producer of Stainless Steel 321 Washer including standard ASTM A193 SS 321 Washer in India. We specialize in offering a vast range of 321 Stainless Steel Washer at very competitive prices to all our customers, domestically and around the world.
We offer products such as Stainless Steel 321 Lock Washer of various grades for optimum performance and robust usage in applications that are very pivotal to any sector or industry. We are a renowned as the largest producer and supplier of SS 321 Fender Washer mainly because of our large and varied inventory of finished products. We stock a wide range of various grades of SS 321 Flat Washer and Stainless Steel 321 Star Washer to cater to the needs of our clients for applications such as in equipment for paper industry, food and chemical processing among other.
We supply on the spot orders of products like Stainless Steel 321 Tab Washer. We are known for supplying Stainless Steel 321 Conical Washer immediately against minimum order Quantity from our storage facilities in order to facilitate a faster delivery. Mahabali also offers Stainless Steel 321 Neoprene Washers, SS 321 Finishing Washers and SS 321 Dock Washer of DIN, ANSI and JIS standards to anywhere across the country and the world. The ASTM standard covers bolting materials for high temperature or high-pressure applications. Our name in the market is reputable as our Stainless Steel 321 Square Washers and Stainless Steel 321 Countersunk Washer are highly commended all across sectors and industries for their quality and durability.
We are one of the leading stainless steel washer manufacturers in India. Being a manufacturer of SS 321 Washers, we ensure that all our products are in accordance with the required standards. Call us today or E-mail Mahabali Steel Centre, SS washer manufacturer and we assure you quality products at reasonable costs.
Stainless Steel Din 1.4541 Wave Washers, Stainless Steel UNS S32100 Metal Washers, Stainless Steel Werkstoff Nr 1.4541 Star Washers, Steel 321 Flat Washer, Stainless Steel 321 Machine Washer, ASTM A193 Belleville Washers Wholesaler & Trader
Stainless Steel 321 Washers Specifications |
|
| Specifications | IS, BS, ASTM |
| Standard | ASTM / ASME - A/ SA 193 |
| Length | 3 mm to 200 mm |
| Size | M02 to M33 |
| Type | Flat Washers, Finishing Washers, Tab Washers, Conical Washers, Special Washers, Belleville Washer, Bonded Sealing Washer, Countersunk Finishing Washer, Dock Washer, Fender Washer, Lock Washer, Neoprene Washer, Square Bevel Washer, Star Washer |
Stainless Steel 321 Washers Equivalent Grades
| AISI Grade Equivalent | STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| AISI 321 | SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
Stainless Steel 321 Washers Sizes |
||||
| Sizes | A | B | C | Weight (lbs.) Per 100 Pieces |
| Inside Diameter | Outside Diameter | Thickness | ||
| 1/2 | 9/16 | 13/8 | 0.109 | 4 |
| 5/8 | 11/16 | 13/4 | 0.134 | 8 |
| 3/4 | 13/16 | 2 | 0.148 | 11 |
| 7/8 | 15/16 | 21/4 | 0.165 | 15 |
| 1 | 11/16 | 21/2 | 0.165 | 19 |
| 11/8 | 11/4 | 23/4 | 0.165 | 22 |
| 11/4 | 13/8 | 3 | 0.165 | 26 |
| 13/8 | 11/2 | 31/4 | 0.180 | 33 |
| 11/2 | 15/8 | 31/2 | 0.180 | 38 |
| 15/8 | 13/4 | 33/4 | 0.180 | 43 |
| 13/4 | 17/8 | 4 | 0.180 | 50 |
| 17/8 | 2 | 41/4 | 0.180 | 57 |
| 2 | 21/8 | 41/2 | 0.180 | 63 |
| 21/4 | 23/8 | 43/4 | 0.220 | 83 |
| 21/2 | 25/8 | 5 | 0.238 | 96 |
| 23/4 | 27/8 | 51/4 | 0.259 | 110 |
| 3 | 31/8 | 51/2 | 0.284 | 130 |
SS UNS S32100 Washers Chemical Composition
| Element | SS 321 |
| Ni | 9.0 – 12.0 |
| C | 0.08 |
| Mn | 2.0 max |
| P | 0.045 max |
| S | 0.030 max |
| Si | 0.75 max |
| Cr | 17.0 – 19.0 |
| Mo | - |
| N | 0.10 |
321 Stainless Steel Washers Mechanical Properties
| Element | SS 321 |
| Tensile Strength (MPa) min | 515 |
| Yield Strength 0.2% Proof (MPa) min | 205 |
| Elongation (% in 50mm) min | 40 |
| Rockwell B (HR B) max Hardness | 95 |
| Brinell (HB) max Hardness | 217 |
321 Stainless Steel Washers Physical Properties
| Element | SS 321 |
| Density(kg/m3) | 8027 |
| Elastic Modulus (GPa) | 193 |
| Mean Coefficient of Thermal Expansion (m/m/°C) | 16.6 / 17.2 / 18.6 |
| Thermal Conductivity (W/m.K) | 16.1 / 22.2 |
| Specific Heat 0-100°C (J/kg.K) | 500 |
| Electrical Resistivity(n.m) | 720 |
Latest Stainless Steel 321 Washers price list:
We Mahabali Steel Center offer best in class Stainless Steel 321 Washers at best market prices in India. Request the Latest Stainless Steel 321 Washers price list using the contact form here.
Stainless Steel 321 Washers Available Types |
|||
| SS 321 Flat Washers | 321 SS Finishing Washers | Steel 321 Tab Washers | 321 Steel Conical Washers |
| SS 321 Special Washers | 321 SS Belleville Washers | Steel 321 Bonded Sealing Washers | 321 Steel Countersunk Finishing Washers |
| SS 321 Dock Washers | 321 SS Fender Washers | Steel 321 Lock Washers | 321 Steel Neoprene Washers |
| SS 321 Square Bevel Washers | 321 SS Star Washers | Steel 321 Spring Washers | 321 Steel Plain Washers |
| SS 321 Metal Washers | 321 SS Wave Washers | Steel 321 Crank Washers | 321 Steel Square Washers |
| SS 321 Hex Washers | 321 SS Star Lock Washers | Steel 321 Aluminium Washers | 321 Steel Thrust Washers |
| SS 321 Serrated Washers | 321 SS Cup Washers | ||
Stainless Steel 321 Washers Available Standards |
|||
| ASTM | ASTM F436 Stainless Steel 321 Washers | ASTM F436M Stainless Steel 321 Washers | ASTM 1985 Stainless Steel 321 Washers |
| DIN | DIN 125 A (ISO 7089) Washers | DIN 125 B (ISO 7090) Washers | DIN 126 Washers |
| DIN 9021 Washers | DIN 440 R Washers | DIN 7349 Washers | |
| DIN 433 Washers | DIN 127 Washers | DIN 128 Washers | |
| DIN 434 Washers | DIN 435 Washers | DIN 1440 Washers | |
| DIN 440v Washers | DIN 6903 Washers | DIN 6916 Washers | |
| DIN 7349 Washers | DIN 7989 Washers | ||
| BS | BS 4320 Form A Washers | BS 4320 Form B Washers | BS 4320 Form C Washers |
| BS 4320 Form D Washers | BS 4395 Washers | ||
| IS / AS | IS 2016 Washers | AS NZS 1252 Washers | |
| JIS | JIS B 1186 Washers | JIS B 1256 Washers | |
| NF | NF E25-513 Z,M Washers | NF E25-513 L,LL Washers | |
