Stainless Steel 430 Washers Manufacturer and Supplier
ASTM A194 / A193 Stainless Steel 430 Washer, SS 430 Washer, Steel UNS S43000 Washer, Stainless Steel Werkstoff Nr. 1.4016 Washer Dealers & Exporters
Award Winning Stainless Steel 430 Washer Stockist, SS 430 Washer Supplier, 430 Steel Washers Manufacture in India
At Mahabali Steel Centre, we are an award winning manufacturing company that is engaged in offering a variety of Stainless Steel 430 Washers at best prices in India and across worldwide clients. We are one of the largest producers of 430 Stainless Steel Washer including ASTM A193 SS 430 Washer in India.
Our SS 430 Washers contains higher amount of chromium content which enable SS 430 Fender Washer and SS 430 Flat Washer increase their resistance to corrosion and their non-magnetic characteristic which finds applications in a variety of industries. We pride ourselves in our design and fabrication process of Stainless Steel 430 Tab Washer and Stainless Steel 430 Star Washer that meets the needs and specifications of our clients. We also supply Stainless Steel 430 Lock Washer to various sectors such as aerospace, metal processing and mining, chemical as well as food processing units all over the globe.
We manufacture and export high-performance Stainless Steel 430 Conical Washer, Stainless Steel 430 Countersunk Washer and Stainless Steel 430 Neoprene Washers under strict supervision of our professional team which guarantees the highest quality. Our clients use SS 430 Dock Washer when a flat surface is needed, during rehabilitation, railings etc. The dimensional accuracy of our products like Stainless Steel 430 Square Washers and SS 430 Finishing Washers are highly appreciated by our clients which makes it easy to install and maintain over long periods of time.
Being the leading S.S. 430 washer manufacturer, we offer products for optimum performance and robust usage. We are the manufacturer of SS 430 Washers that provide materials which are in strict compliance with the national and international standards. Contact us for the best stainless steel washer manufacturers in India and help us serve you better.
Stainless Steel Din 1.4016 Wave Washers, Stainless Steel UNS S43000 Metal Washers, Stainless Steel Werkstoff Nr 1.4016 Star Washers, Steel 430 Flat Washer, Stainless Steel 430 Machine Washer, ASTM A193 Belleville Washers Wholesaler & Trader
Stainless Steel 430 Washers Specifications |
|
| Specifications | IS, BS, ASTM |
| Standard | ASTM / ASME - A/ SA 193 |
| Length | 3 mm to 200 mm |
| Size | M02 to M33 |
| Type | Flat Washers, Finishing Washers, Tab Washers, Conical Washers, Special Washers, Belleville Washer, Bonded Sealing Washer, Countersunk Finishing Washer, Dock Washer, Fender Washer, Lock Washer, Neoprene Washer, Square Bevel Washer, Star Washer |
Stainless Steel 430 Washers Equivalent Grades
| AISI Grade Equivalent | STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| AISI 430 | SS 430 | - | S43000 | SUS 430 | - |
Stainless Steel 430 Washers Sizes |
||||
| Sizes | A | B | C | Weight (lbs.) Per 100 Pieces |
| Inside Diameter | Outside Diameter | Thickness | ||
| 1/2 | 9/16 | 13/8 | 0.109 | 4 |
| 5/8 | 11/16 | 13/4 | 0.134 | 8 |
| 3/4 | 13/16 | 2 | 0.148 | 11 |
| 7/8 | 15/16 | 21/4 | 0.165 | 15 |
| 1 | 11/16 | 21/2 | 0.165 | 19 |
| 11/8 | 11/4 | 23/4 | 0.165 | 22 |
| 11/4 | 13/8 | 3 | 0.165 | 26 |
| 13/8 | 11/2 | 31/4 | 0.180 | 33 |
| 11/2 | 15/8 | 31/2 | 0.180 | 38 |
| 15/8 | 13/4 | 33/4 | 0.180 | 43 |
| 13/4 | 17/8 | 4 | 0.180 | 50 |
| 17/8 | 2 | 41/4 | 0.180 | 57 |
| 2 | 21/8 | 41/2 | 0.180 | 63 |
| 21/4 | 23/8 | 43/4 | 0.220 | 83 |
| 21/2 | 25/8 | 5 | 0.238 | 96 |
| 23/4 | 27/8 | 51/4 | 0.259 | 110 |
| 3 | 31/8 | 51/2 | 0.284 | 130 |
SS UNS S43000 Washers Chemical Composition
| Element | SS 430 |
| Ni | 0.75 |
| C | 0.12 |
| Mn | 1.0 max |
| P | 0.040 max |
| S | 0.030 max |
| Si | 1.0 max |
| Cr | 16.0 – 18.0 |
| Mo | - |
| N | - |
430 Stainless Steel Washers Mechanical Properties
| Element | SS 430 |
| Tensile Strength (MPa) min | 450 |
| Yield Strength 0.2% Proof (MPa) min | 205 |
| Elongation (% in 50mm) min | 22 |
| Rockwell B (HR B) max Hardness | 89 |
| Brinell (HB) max Hardness | 183 |
430 Stainless Steel Washers Physical Properties
| Element | SS 430 |
| Density(kg/m3) | 7750 |
| Elastic Modulus (GPa) | 200 |
| Mean Coefficient of Thermal Expansion (m/m/°C) | 10.4 / 11.0 / 11.4 |
| Thermal Conductivity (W/m.K) | 23.9 / 26.1 |
| Specific Heat 0-100°C (J/kg.K) | 460 |
| Electrical Resistivity(n.m) | 600 |
Latest Stainless Steel 430 Washers price list:
We Mahabali Steel Center offer best in class Stainless Steel 430 Washers at best market prices in India. Request the Latest Stainless Steel 430 Washers price list using the contact form here.
Stainless Steel 430 Washers Available Types |
|||
| SS 430 Flat Washers | 430 SS Finishing Washers | Steel 430 Tab Washers | 430 Steel Conical Washers |
| SS 430 Special Washers | 430 SS Belleville Washers | Steel 430 Bonded Sealing Washers | 430 Steel Countersunk Finishing Washers |
| SS 430 Dock Washers | 430 SS Fender Washers | Steel 430 Lock Washers | 430 Steel Neoprene Washers |
| SS 430 Square Bevel Washers | 430 SS Star Washers | Steel 430 Spring Washers | 430 Steel Plain Washers |
| SS 430 Metal Washers | 430 SS Wave Washers | Steel 430 Crank Washers | 430 Steel Square Washers |
| SS 430 Hex Washers | 430 SS Star Lock Washers | Steel 430 Aluminium Washers | 430 Steel Thrust Washers |
| SS 430 Serrated Washers | 430 SS Cup Washers | ||
Stainless Steel 430 Washers Available Standards |
|||
| ASTM | ASTM F436 Stainless Steel 430 Washers | ASTM F436M Stainless Steel 430 Washers | ASTM 1985 Stainless Steel 430 Washers |
| DIN | DIN 125 A (ISO 7089) Washers | DIN 125 B (ISO 7090) Washers | DIN 126 Washers |
| DIN 9021 Washers | DIN 440 R Washers | DIN 7349 Washers | |
| DIN 433 Washers | DIN 127 Washers | DIN 128 Washers | |
| DIN 434 Washers | DIN 435 Washers | DIN 1440 Washers | |
| DIN 440v Washers | DIN 6903 Washers | DIN 6916 Washers | |
| DIN 7349 Washers | DIN 7989 Washers | ||
| BS | BS 4320 Form A Washers | BS 4320 Form B Washers | BS 4320 Form C Washers |
| BS 4320 Form D Washers | BS 4395 Washers | ||
| IS / AS | IS 2016 Washers | AS NZS 1252 Washers | |
| JIS | JIS B 1186 Washers | JIS B 1256 Washers | |
| NF | NF E25-513 Z,M Washers | NF E25-513 L,LL Washers | |
