Stainless Steel 316 Washers Manufacturer and Supplier
ASTM A194 / A193 Stainless Steel 316 Washer, SS 316 Washer, Steel UNS S31600 Washer, Stainless Steel Werkstoff Nr. 1.4401 Washer Dealers & Exporters
Award Winning Stainless Steel 316 Washer Stockist, SS 316 Washer Supplier, 316 Steel Washers Manufacture in India
Mahabali Steel Centre is an eminent Stainless Steel 316 Washer manufacturer offering ASTM A193 SS 316 Washer to a wide base of clients across a number of industries. We are one of the leading 316 Stainless Steel Washer Supplier to food, chemical and electrical industries.
We offer Stainless Steel 316 Lock Washer in customized shapes and sizes to fit our customer’s needs. SS 316 Fender Washer has a high resistance to corrosion from both organic and inorganic chemicals. Mahabali supplies the highest quality Stainless Steel 316 Star Washer and Stainless Steel 316 Tab Washer for use in extreme conditions. Our SS 316 Flat Washers and SS 316 Dock Washer are highly durable and useful due to which these are highly appreciated in the market.
Our quality controllers strictly supervise the fabrication of Stainless Steel 316 Conical Washer and Stainless Steel 316 Neoprene Washers and these bars are designed based on varied parameters of quality before the delivery of these products.
All our products including SS 316 Finishing Washers, Stainless Steel 316 Square Washers and Stainless Steel 316 Countersunk Washer are in compliance with the national and international standards. Contact Mahabali Steel Centre of S.S 316 washer manufacturer for your requirements and we assure you a high-quality speedy delivery from the most professional stainless steel washer manufacturers in India.
Stainless Steel Din 1.4401 Wave Washers, Stainless Steel UNS S31600 Metal Washers, Stainless Steel Werkstoff Nr 1.4401 Star Washers, Steel 316 Flat Washer, Stainless Steel 316 Machine Washer, ASTM A193 Belleville Washers Wholesaler & Trader
Stainless Steel 316 Washers Specifications |
|
| Specifications | IS, BS, ASTM |
| Standard | ASTM / ASME - A/ SA 193 |
| Length | 3 mm to 200 mm |
| Size | M02 to M33 |
| Type | Flat Washers, Finishing Washers, Tab Washers, Conical Washers, Special Washers, Belleville Washer, Bonded Sealing Washer, Countersunk Finishing Washer, Dock Washer, Fender Washer, Lock Washer, Neoprene Washer, Square Bevel Washer, Star Washer |
Stainless Steel 316 Washers Equivalent Grades
| AISI Grade Equivalent | STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| AISI 316 | SS 316 | 1.4401 | S31600 | SUS 316 | X5CrNiMo17-12-2 |
Stainless Steel 316 Washers Sizes |
||||
| Sizes | A | B | C | Weight (lbs.) Per 100 Pieces |
| Inside Diameter | Outside Diameter | Thickness | ||
| 1/2 | 9/16 | 13/8 | 0.109 | 4 |
| 5/8 | 11/16 | 13/4 | 0.134 | 8 |
| 3/4 | 13/16 | 2 | 0.148 | 11 |
| 7/8 | 15/16 | 21/4 | 0.165 | 15 |
| 1 | 11/16 | 21/2 | 0.165 | 19 |
| 11/8 | 11/4 | 23/4 | 0.165 | 22 |
| 11/4 | 13/8 | 3 | 0.165 | 26 |
| 13/8 | 11/2 | 31/4 | 0.180 | 33 |
| 11/2 | 15/8 | 31/2 | 0.180 | 38 |
| 15/8 | 13/4 | 33/4 | 0.180 | 43 |
| 13/4 | 17/8 | 4 | 0.180 | 50 |
| 17/8 | 2 | 41/4 | 0.180 | 57 |
| 2 | 21/8 | 41/2 | 0.180 | 63 |
| 21/4 | 23/8 | 43/4 | 0.220 | 83 |
| 21/2 | 25/8 | 5 | 0.238 | 96 |
| 23/4 | 27/8 | 51/4 | 0.259 | 110 |
| 3 | 31/8 | 51/2 | 0.284 | 130 |
SS UNS S31600 Washers Chemical Composition
| Element | SS 316 |
| Ni | 10.0 – 14.0 |
| C | 0.035 |
| Mn | 2.0 max |
| P | 0.045 max |
| S | 0.030 max |
| Si | 0.75 max |
| Cr | 16.0 – 18.0 |
| Mo | 2.00 - 3.00 |
| N | 0.10 |
316 Stainless Steel Washers Mechanical Properties
| Element | SS 316 |
| Tensile Strength (MPa) min | 515 |
| Yield Strength 0.2% Proof (MPa) min | 205 |
| Elongation (% in 50mm) min | 40 |
| Rockwell B (HR B) max Hardness | 95 |
| Brinell (HB) max Hardness | 217 |
316 Stainless Steel Washers Physical Properties
| Element | SS 316 |
| Density(kg/m3) | 8000 |
| Elastic Modulus (GPa) | 193 |
| Mean Coefficient of Thermal Expansion (m/m/°C) | 15.9 / 16.2 / 17.5 |
| Thermal Conductivity (W/m.K) | 16.3 / 21.5 |
| Specific Heat 0-100°C (J/kg.K) | 500 |
| Electrical Resistivity(n.m) | 740 |
Latest Stainless Steel 316 Washers price list:
We Mahabali Steel Center offer best in class Stainless Steel 316 Washers at best market prices in India. Request the Latest Stainless Steel 316 Washers price list using the contact form here.
Stainless Steel 316 Washers Available Types |
|||
| SS 316 Flat Washers | 316 SS Finishing Washers | Steel 316 Tab Washers | 316 Steel Conical Washers |
| SS 316 Special Washers | 316 SS Belleville Washers | Steel 316 Bonded Sealing Washers | 316 Steel Countersunk Finishing Washers |
| SS 316 Dock Washers | 316 SS Fender Washers | Steel 316 Lock Washers | 316 Steel Neoprene Washers |
| SS 316 Square Bevel Washers | 316 SS Star Washers | Steel 316 Spring Washers | 316 Steel Plain Washers |
| SS 316 Metal Washers | 316 SS Wave Washers | Steel 316 Crank Washers | 316 Steel Square Washers |
| SS 316 Hex Washers | 316 SS Star Lock Washers | Steel 316 Aluminium Washers | 316 Steel Thrust Washers |
| SS 316 Serrated Washers | 316 SS Cup Washers | ||
Stainless Steel 316 Washers Available Standards |
|||
| ASTM | ASTM F436 Stainless Steel 316 Washers | ASTM F436M Stainless Steel 316 Washers | ASTM 1985 Stainless Steel 316 Washers |
| DIN | DIN 125 A (ISO 7089) Washers | DIN 125 B (ISO 7090) Washers | DIN 126 Washers |
| DIN 9021 Washers | DIN 440 R Washers | DIN 7349 Washers | |
| DIN 433 Washers | DIN 127 Washers | DIN 128 Washers | |
| DIN 434 Washers | DIN 435 Washers | DIN 1440 Washers | |
| DIN 440v Washers | DIN 6903 Washers | DIN 6916 Washers | |
| DIN 7349 Washers | DIN 7989 Washers | ||
| BS | BS 4320 Form A Washers | BS 4320 Form B Washers | BS 4320 Form C Washers |
| BS 4320 Form D Washers | BS 4395 Washers | ||
| IS / AS | IS 2016 Washers | AS NZS 1252 Washers | |
| JIS | JIS B 1186 Washers | JIS B 1256 Washers | |
| NF | NF E25-513 Z,M Washers | NF E25-513 L,LL Washers | |
