Stainless Steel 316 Bolts Manufacturer and Supplier

Stainless Steel 316 Bolts, SS 316 Bolts, ASTM A194 / A193 UNS S31600 Bolts, Stainless Steel Werkstoff Nr. 1.4401 Bolts, Stainless Steel 316 Bolts & Nuts, SS 316 Lifting Eye Bolts, Dealers & Exporters

SS 316 Eye Bolts, Steel 316 Allen Bolts, Stainless Steel 316 U Bolt, 316 Steel U Bolts, SS 316 Lag Bolts, Austenitic Stainless Steel 316 Carriage Bolts, Stainless Steel 316 Stud Bolt, Steel 316 T Bolt Stockists & Supplier

  • SS 316 Bolt
  • 316 SS Bolt
  • 316 Steel Bolt
  • Stainless Steel 316 Bolt

Mahabali Steel Centre is one of the largest supplier and manufacturers of Stainless Steel 316 Bolts in India and across globally. We ensure that all our SS 316 Bolts are in compliance with the national and international standards.

Our clients prefer our 316 Stainless Steel Bolt / UNS S31600 Bolts as it is the most common type of bolt used in structural connections. We offer these 18/8” 316 Stainless Steel Bolt that manufactured using the high standard raw material to various sectors like engineering, construction, oil field, offshore, shipbuilding among others.

We offer wide range of grade 316 SS Bolts in different forms such as Stainless Steel 316 Eye Bolts, SS 316 Allen Bolts, SS 316 U Bolts, SS 316 T Bolts, 316 Stainless Steel T Bolts, SS 316 Lifting Eye Bolts, 316 Stainless Steel Square Head Bolts, Stainless Steel 316 Hex Head Bolts, SS 316 Carriage Bolts, SS 316 Countersunk Bolts and many more.

In order to offer a highly commendable range of Stainless Steel Grade 316 Bolt, we adhere to a highly acclaimed and recommended industrial standards and supervision. We assure you the products of very high quality and durability which meets your needs and specifications and a very speedy delivery. Kindly do contact us for your specific SS 316 Bolts requirements.

SS 316 Hanger Bolts Dealer, DIN 931 SS 316 Foundation Bolts, Stainless Steel 316 Structural Bolts Trader, DIN 933 SS 316 Countersunk Bolt, SS 316 Square Head Bolts, Stainless Steel 316 Jack Bolt Wholesalers


Stainless Steel 316 Bolt Specifications

Specifications IS, BS, ASTM
Standard ASTM / ASME - A/ SA 193
Length 3 mm to 200 mm
Size M02 to M33
Type Eye Bolt, Allen Bolt, Hex Head Bolt, Hanger Bolts, Carriage Bolt, Jack Bolt, Square Head Bolts, Lag Bolts, U Bolt, Elevator Bolts, Steel Bolts, Hex Flange Bolt, Structural Bolts, Step Bolt, Square Head Machine Bolts, Plow Bolts, Metric Bolts, Hex Tap Bolt, Hex Machine Bolt, Shoulder Eye Bolt, Serrated Flange Bolt, Turned Eye Bolt, Long Bolts, Bent Bolt, Square U Bolts, Timber Bolts, 12 Point Flange Bolt, Heavy Hex Bolt, Button Head Bolts, Hexagon Flange Bolt, Stud Bolt, Hexagon Head Bolt, Lifting Eye Bolt, T Bolt, Countersunk Bolt, Threaded Bolts

Stainless Steel 316 Bolt Equivalent Grades

AISI Grade Equivalent STANDARD WERKSTOFF NR. UNS JIS EN
AISI 316 SS 316 1.4401 S31600 SUS 316 X5CrNiMo17-12-2

Stainless Steel 316 Bolts Sizes

Stainless Steel 316 Bolts Sizes Stainless Steel 316 Bolts size chart Stainless Steel 316 Bolts size guide Stainless Steel 316 Bolts dimensions
3/8″-16 x 1″ Grade 5 Finish Stainless Steel 316 Bolts 1/2″-13 x 1-1/2″ Grade 5 Finish Stainless Steel 316 Bolts 1/4″-20 x 1″ Grade 5 Finish Stainless Steel 316 Bolts
3/8″-16 x 1-1/4″ Grade 5 Finish Stainless Steel 316 Bolts 3/8″-16 x 1-1/2″ Grade 5 Finish Stainless Steel 316 Bolts 1/4″-20 x 3/4″ Grade 5 Finish Stainless Steel 316 Bolts
1/2″-13 x 2″ Grade 8 Yellow Finish Stainless Steel 316 Bolts 1/2″-13 x 2″ Grade 5 Finish Stainless Steel 316 Bolts 1/2″-13 x 1-1/2″ Grade 8 Yellow Finish Stainless Steel 316 Bolts
5/8″-11 x 2″ Grade 8 Yellow Finish Stainless Steel 316 Bolts 1/4″-20 x 3/4″ Grade 18-8 Stainless Steel Stainless Steel 316 Bolts 5/16″-18 x 1″ Grade 5 Finish Stainless Steel 316 Bolts
3/8″-16 x 1″ Grade 8 Yellow Finish Stainless Steel 316 Bolts 3/8″-16 x 1″ Grade 18-8 Stainless Steel Stainless Steel 316 Bolts 3/8″-16 x 1-1/2″ Grade 8 Yellow Finish Stainless Steel 316 Bolts
1/4″-20 x 1″ Grade 18-8 Stainless Steel Stainless Steel 316 Bolts 5/8″-11 x 2″ Grade 5 Finish Stainless Steel 316 Bolts 5/8″-11 x 2-1/2″ Grade 8 Yellow Finish Stainless Steel 316 Bolts
3/8″-16 x 2″ Grade 5 Finish Stainless Steel 316 Bolts 3/8″-16 x 1-1/4″ Grade 8 Yellow Finish Stainless Steel 316 Bolts

SS UNS S31600 Bolt Chemical Composition

Element SS 316
Ni 10.0 – 14.0
C 0.08
Mn 2.0 max
P 0.045 max
S 0.03 max
Si 0.75 max
Cr 16.0 – 18.0
Mo 2.00 - 3.00
N 0.10

316 Stainless Steel Bolt Mechanical Properties

Element SS 316
Tensile Strength (MPa) min 515
Yield Strength 0.2% Proof (MPa) min 205
Elongation (% in 50mm) min 40
Rockwell B (HR B) max Hardness 95
Brinell (HB) max Hardness 217

316 Stainless Steel Bolt Physical Properties

Element SS 316
Density(kg/m3) 8000
Elastic Modulus (GPa) 193
Mean Coefficient of Thermal Expansion (m/m/°C) 15.9 / 16.2 / 17.5
Thermal Conductivity (W/m.K) 16.3 / 21.5
Specific Heat 0-100°C (J/kg.K) 500
Electrical Resistivity(n.m) 740

Latest stainless steel 316 bolts and nuts prices list:

We Mahabali Steel Center offer best in class stainless steel 316 bolts at best market prices in India. Request the Latest stainless steel 316 bolts and nuts price list using the contact form here.

Stainless Steel 316 Bolts Available Types

SS 316 Eye Bolts 316 SS Allen Bolts Steel 316 Hex Head Bolts 316 Steel Hanger Bolts
SS 316 Carriage Bolts 316 SS Jack Bolts Steel 316 Square Head Bolts 316 Steel Lag Bolts
SS 316 U Bolts 316 SS Elevator Bolts Steel 316 Steel Bolts 316 Steel Hex Flange Bolts
SS 316 Structural Bolts 316 SS Step Bolts Steel 316 Square Head Machine Bolts 316 Steel Plow Bolts
SS 316 Metric Bolts 316 SS Hex Tap Bolts Steel 316 Hex Machine Bolts 316 Steel Shoulder Eye Bolts
SS 316 Serrated Flange Bolts 316 SS Turned Eye Bolts Steel 316 Long Bolts 316 Steel Bent Bolts
SS 316 Square U Bolts 316 SS Timber Bolts Steel 316 12 Point Flange Bolts 316 Steel Heavy Hex Bolts
SS 316 Button Head Bolts 316 SS Hexagon Flange Bolts Steel 316 Stud Bolts 316 Steel Hexagon Head Bolts
SS 316 Lifting Eye Bolts 316 SS T Bolts Steel 316 Countersunk Bolts 316 Steel Threaded Bolts

Stainless Steel 316 Bolts Available Standards

ASTM ASTM A193 Stainless Steel 316 Bolts ASTM A307 Stainless Steel 316 Bolts ASTM A320 Stainless Steel 316 Bolts
ASTM A325 Stainless Steel 316 Bolts ASTM A354 Stainless Steel 316 Bolts ASTM A449 Stainless Steel 316 Bolts
ASTM A490 Stainless Steel 316 Bolts ASTM F568 Stainless Steel 316 Bolts ASTM F593 Stainless Steel 316 Bolts
ASTM F1554 Stainless Steel 316 Bolts ASTM A325M Stainless Steel 316 Bolts ASTM A490M Stainless Steel 316 Bolts
IS IS 1363 Bolts IS 1364 Bolts IS 2585 Bolts
IS 3138 Bolts IS 3640 Bolts IS 10238 Bolts
IS 3757 Bolts IS 6639 Bolts
DIN DIN 931 Bolts DIN 933 Bolts DIN 960 Bolts
DIN 961 Bolts DIN 7990 Bolts DIN 610 Bolts
DIN 6914 Bolts DIN 6915 Bolts
BS BS 1083 Bolts BS 1768 Bolts BS 1769 Bolts
ANSI ANSI B18.2.1 Bolts
ISO ISO 7412 Bolts
