Manufacturer & Supplier of DIN 933 Hexagon Head Bolts, Metric DIN 933 Hex Head Machine Bolts as per custom specification in Mumbai, India
ASTM 194 Stainless Steel DIN 933 Hexagon Head Bolts, DIN 933 Carbon Steel Hex Head Bolts, DIN 933 Alloy Steel Hexagon Head Bolts, Nickel Alloy Hexagon Head Bolts DIN 933 Exporter & Stockist
At Mahabali Steel Centre, we are highly engaged in offering a wide gamut of best quality DIN 933 - Hexagon Head Bolts in a wide range of thicknesses, lengths, grades and materials in India and across worldwide clientele at affordable rates.
As a leading manufacturer and supplier, we stock a large number of DIN 933 Hex Head Bolts with metric thread to meet preferred needs of our esteemed customers. These hex-head bolts with partial threads and threaded along the entire length according to DIN 933 made to fit a variety of standards – Indian, German, Japanese, American and British.
Our offered high tensile hexagon head bolts which zinc galvanized for corrosion protection. It includes DIN 933 Stainless Steel Hexagon Head Bolts, DIN 933 Carbon Steel Hexagon Head Bolts, DIN 933 Nickel Alloy Hexagon Head Bolts, and DIN 933 Alloy Steel Hexagon Head Bolts etc.
ASME SAE 193 Hot Dip Galvanized SS DIN 933 Hexagon Head Bolts, DIN 933 SS 304 Hexagon Head Bolts Exporter, DIN 933 SS 316 Hexagon Head Bolts Supplier, Stockholder in India
We export and design premium quality hexagon head bolts that correspond to ISO 4017; CSN 21103; PN 82105; NI 5739; EU 24017; equivalent norms. Kindly do call us today or send an inquiry to get a free quote or to discuss regarding our quality products!
DIN 933 Hexagon Head Bolts Specifications |
|
| Standards | ASTM / ASME SB 160 / 164 / 425 / 166 / 446 / 574 / 472 / A/SA 193 / 194 / 194 GR / UNS NO. S 31803, S 32205 |
| Length | 3 mm to 200 mm |
| Size | M02 to M33 |
| DIN 933 Hexagon Head Bolts Manufacturer | GKW, Unbrako, Kundan, APL, Sundaram Precision, EBY Fastener Etc. |
| Material | Stainless Steel, Low carbon steel, Alloy carbon steel, High Tensile, Nickel Alloy, Alloy Steel, Mild Steel, Copper, Brass, Aluminium |
| Stainless Steel DIN 933 Hexagon Head Bolts in Grade | SS 304, SS 304L, SS 309, SS 310, SS 316, SS 316L, SS 317, SS 317L, SS 321, SS 330, SS 347, SS 410, SS 430, SS 440C |
| Nickel Alloy DIN 933 Hexagon Head Bolts | Hastelloy DIN 933 Hexagon Head Bolts, Cupro Nickel DIN 933 Hexagon Head Bolts, Nickel DIN 933 Hexagon Head Bolts, Monel DIN 933 Hexagon Head Bolts, Inconel DIN 933 Hexagon Head Bolts, Alloy 20 DIN 933 Hexagon Head Bolts |
| Finish | Plain, black, zinc plated (Cr,3+), zinc plated(Cr,6+), hot dipped galvanized, dacromet, nickel plated, cadmium plated, etc. |
| Packing | IN BULK :canton/pallet, Small Boxs/carton/ pallet, or customer request |
DIN 933 Hexagon Head Bolts Sizes |
|||
| DIN 933 Hexagon Head Bolts Sizes | DIN 933 Hexagon Head Bolts size chart | DIN 933 Hexagon Head Bolts size guide | DIN 933 Hexagon Head Bolts dimensions |
| 3/8″-16 x 1-1/2″ DIN 933 Hexagon Head Bolts | 3/8″-16 x 1-1/4″ DIN 933 Hexagon Head Bolts | 3/4″-10 x 3″ DIN 933 Hexagon Head Bolts | |
| 1/2″-13 x 3″ DIN 933 Hexagon Head Bolts | 1/2″-13 x 2-1/2″ DIN 933 Hexagon Head Bolts | 5/16″-18 x 1″ DIN 933 Hexagon Head Bolts | |
| 3/8″-16 x 1″ DIN 933 Hexagon Head Bolts | 5/8″-11 x 3″ DIN 933 Hexagon Head Bolts | 3/8″-16 x 3/4″ DIN 933 Hexagon Head Bolts | |
| 1/2″-13 x 1-1/2″ DIN 933 Hexagon Head Bolts | 1/2″-13 x 2″ DIN 933 Hexagon Head Bolts | 5/16″-18 x 1-1/4″ DIN 933 Hexagon Head Bolts | |
| 1/4″-20 x 1″ DIN 933 Hexagon Head Bolts | 3/8″-16 x 2″ DIN 933 Hexagon Head Bolts | 5/8″-11 x 4″ DIN 933 Hexagon Head Bolts | |
| 5/8″-11 x 2-1/2″ DIN 933 Hexagon Head Bolts | 3/8″-16 x 2-1/2″ DIN 933 Hexagon Head Bolts | 3/8″-16 x 3″ DIN 933 Hexagon Head Bolts | |
| 1/2″-13 x 1-1/4″ DIN 933 Hexagon Head Bolts | 3/4″-10 x 2-1/2″ DIN 933 Hexagon Head Bolts | ||
DIN 933 Hexagon Head Bolts Dimensions
|
Diameter
|
M5
|
M6
|
M8
|
M10
|
M12
|
M16
|
M20
|
M24
|
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
k
|
3.5
|
4
|
5.3
|
6.4
|
7.5
|
10
|
12.5
|
15
|
||||||||
|
s max
|
8
|
10
|
13
|
17
|
19
|
24
|
30
|
36
|
||||||||
|
e min
|
8.79
|
11.05
|
14.38
|
18.9
|
21.1
|
26.75
|
33.53
|
39.98
|
||||||||
|
b up to 125
|
16
|
18
|
22
|
26
|
30
|
38
|
46
|
54
|
||||||||
|
b up to 200
|
—
|
24
|
28
|
32
|
36
|
44
|
52
|
60
|
||||||||
Latest DIN 933 Hexagon Head Bolts prices list:
We Mahabali Steel Center offer best in class DIN 933 Hexagon Head Bolts at best market prices in India. Request the Latest DIN 933 Hexagon Head Bolts price list using the contact form here.
SS DIN 933 Hexagon Head Bolts Available Grades |
|
|
|
DIN 933 Hexagon Head Bolts Available Standards |
|||
| ASTM | ASTM A307 Hexagon Head Bolts | ASTM A325M Hexagon Head Bolts | ASTM A490M Hexagon Head Bolts |
| IS | IS 1363 Hexagon Head Bolts | IS 1364 Hexagon Head Bolts | IS 2585 Hexagon Head Bolts |
| IS 3138 Hexagon Head Bolts | IS 3640 Hexagon Head Bolts | IS 10238 Hexagon Head Bolts | |
| IS 3757 Hexagon Head Bolts | IS 6639 Hexagon Head Bolts | ||
| BS | BS 1083 Hexagon Head Bolts | BS 1768 Hexagon Head Bolts | BS 1769 Hexagon Head Bolts |
| ANSI | ANSI B18.2.1 Hexagon Head Bolts | ||
| ISO | ISO 7412 Hexagon Head Bolts | ||
Value Added Services of DIN 933 Hexagon Head Bolts |
|
|
|
|
|---|---|
| Mechanical Testing Such as Tensile of Area | Commercial Invoice including HS Code |
| Hardness Test | Packing List including Complete Details |
| Chemical Analysis – Spectro Analysis | Certificate of Origin legalized |
| Positive Material Identification – PMI Testing | Material Traceability Records |
| Flattening Test | Quality Assurance Plan (QAP) |
| Micro and MacroTest | Heat Treatment Charts |
| Pitting Resistance Test | Material Test Certificates (MTC) |
| Flaring Test | Guarantee Letter |
| Intergranular Corrosion (IGC) Test | NABL approved Laboratory Test Reports |
